Schaefer Vertical Spring Block for Standing Workstations

Description

Features:

• Stand up spring block for 1-1/4″ T-Track.
• Stainless Steel cheeks and stainless steel slider ensure reliability.
• Polyethylene liner and pin stop allow for easy adjustment.

Specifications:

• Track Size: 1-1/4″ x 3/16″ (32 mm x 5 mm)
• Sheave Diameter: 2-3/8″ (60 mm)
• Max Line: 1/2″ (12 mm)
• Length: 4″ (102 mm)
• Width: 1-9/16″ (39 mm)
• Height: 4-15/16″ (126 mm)
• Bearing Height: 2-3/8″ (67 mm)
• Safe Working Load: 2250 lbs. (1020 kg)
• Weight: 14 oz. (397 g)
