Garmin IFD440 Touchscreen Avionics: Integrated FMS, GPS Navigation, and Communication System

Description

 IFD440 Touch Screen FMS/GPS/NAV/COM

Avidyne’s IFD440 FMS/GPS/NAV/COM combines the best Flight Management System available, with a multi-channel digital VHF radio, in an easy-to-use, plug & play design.  Easy-to-use touchscreen interface with knobs and buttons including WiFi/Bluetooth^® capabilities. Plug & Play ReplacementsThe IFD440 is a physical plug & play replacements for the Garmin GNS430 and GNS430W, using the existing tray and connectors.  They are compatible with all the popular interface configurations, which can greatly minimize installation costs.   The Easy ChoiceThe IFD440 represents the next generation in FMS/GPS/ NAV/COM systems. Each provides VHF communication and SBAS/ LPV precision navigation and are designed to meet the accuracy and integrity requirements for ADS-B as part of the NextGen airspace initiative. As plug-and play replacements for legacy systems, the IFD440 shares the same basic functionality in large and compact display formats.When it comes to panel-mounted avionics, you now have a choice and the choice is easy. Avidyne. Hybrid Touch: Knobs & Buttons or Touch-ScreenOur award-winning Page & Tab user interface allows you to go to any page in the system with only one or two clicks.In addition to the dedicated knobs and buttons that many pilots prefer for frequent pilot actions, the IFD440’s Hybrid Touch capability allows pilots to perform virtually all of those same functions via the touch-screen interface, as well as providing additional MultiTouch functionality like pinch-zoom, map panning, and graphical flight plan editing, allowing the pilot to decide to use the MultiTouch screen, or knobs and buttons depending on the pilot’s phase of flight.Avidyne’s unique Hybrid Touch user interface eliminates nested menus and allows pilots to view any page with only one or two clicks. Made by Pilots for PilotsThe IFD440 was designed for ease of use, especially during single-pilot IFR operations. As avid and enthusiastic pilots, we at Avidyne understand the importance of workload reduction and simplicity of operation.The IFD440 provide an easy page & tab user interface, plus advanced radio management including automated NAV frequency tuning and COM frequency nomination, automatic frequency identification, easy-to-modify graphical flight planning, and Avidyne’s exclusive GeoFill™ waypoint nomination. Specifications  Display4.8” Diagonal w/Touch ScreenFull VGA – 640 x 235 pixels65,535 colorsUltrabright sunlight readable w/LED Backlighting Dimensions Width: 6.30″ (16.0cm)Height: 2.66“ (6.73cm)Depth: 11.00“(27.5cm) behind panel including connectors Weight 6.6 lbs (3.79kg) including tray & connector VHF COM Power Output10 Watts nominalOptional 16Watt (for 28vdc installations only) Power Requirements11 – 33VDC4.4A/6.5A Xmit @14vdc2.2A/4.0A Xmit @28vdc EnvironmentalDO 160ETo 50,000 ft.-20C to +55C Operating+70C Short Term Functionality Satellite Datalink Weather InterfaceAvidyne MLB700/WSI AV-300 Broadcast Datalink Receiver – Using WSI InFlight® Aviation Weather & SIRIUS® Satellite RadioGarmin GDL69/A Broadcast Datalink Receiver – Using Baron Services Weather & XM Satellite RadioHeads Up Technologies XMD-076/A Broadcast Datalink Receiver– Using Baron Services Weather and XM Satellite Radio Electronic Approach Charts & Airport Diagrams CMax™ – Jeppesen Electronic Airway Manual Charts Lightning InterfaceAvidyne TWX670 Tactical Lightning DetectionL3 WX-500 Stormscope® Weather Mapping Sensor Traffic InterfaceAvidyne TAS600/605/610/615/620/A TASRyan 9900B/BX TASHoneywell KTA870/KMH880 TAS/IHASL3 Skywatch 497 / HP TASGarmin GTS800/820 TASHoneywell CAS66A TCAS IL3 791 TCAS IGarmin GTS850 TCAS IADS-B InterfaceAvidyne TAS605A/TAS615A/ TAS620A (Traffic) Charts, Nav Data, and other software updates are easily field loadable via USB.
