Description
After the successful release of the BEP 701,720 and 721 battery switches BEP has listened to customer feedback concerning some installations where switches need to be recessed through varying thickness of panels. The 700 Easyfit achieves through an easily removable threaded ring allowing for panel thickness up to 19mm (3/4inch).
The 700 Easyfit possesses many of the features present in the 701 Contour Battery Master Switch such as the ability to remove the key by rotating it 45 degree past the off position, labelled handle and removable back cover concealing exposed terminals to meet ABYC specifications.
- Continuous rating: 275 amps
- DC Intermittent rating: 455 Amps
- DC Cranking Amps: 1250 Amps
- DC Voltage rating: 48 Volts
- DC Operation: On/Off
- Mounting: Recessed or surface
- Termination stud size: 2 x 10mm
- Stuand nut: Tin Plated copper
- UL Rating: Tested to UL Specifications
- Ignition protecd
