Description
Item# 3116
Features:
- Includes one 120V AC / 30A ELCI Main and three blank positions
- Blank apertures for custom breaker loading
- Glass filled polycarbonate mounting box
- Clear cover allows easy view of circuit breaker status
- Overlapping cover for strength and increased gasket protection
- Oversized, formed in place seamless PUR gasket
- Easily removable stainless steel hinge pin for unobstructed installation
- Stainless steel latch secures cover without penetrating the enclosure
- Stainless steel mounting hardware included
- Includes waterproof glands
Specifications:
- Minimum Operating Temperature:-40° C
- Maximum Operating Temperature:85° C
- Cover Screws and Hardware:10-32 Stainless Steel
- Enclosure Size:6.0″ x 6.0″ x 4.0″
- (152mm x 152mm x 102mm)
- Exterior Overall Dimensions:7.6″ x 7.4″ x 4.7″
- (192mm x 188mm x 120mm)
- Mounting Hardware:1/4″ Diameter, 12 (6 mm)
- Weight:7.00lb (3.18 kg)
