Blue Seas AC 1-Position 360° Marine Distribution Panel

Description

Item# 1190

Features:

• One 30A AC ELCI Main Residual Current Circuit Breaker, leakage trip amperate – 30 mA
• ELCI provides overcurrent and leakage protection per ABYC E-11 for whole boat shore power protection
• One 15A AC Branch Flat Rocker Circuit Breaker
• Red ” Reverse Polarity” LED
• Includes 4206 AC Panel Basic Square Format Label Set
• “ON” indicating LEDs

Specifications:

• Positions:1
• Nominal Voltage:120V AC
• Backlit Label: Green LED
• Height:4.75in (120.65 mm)
• Width:4.88in (123.95 mm)
• Depth:3.99in (101.35 mm)
• Weight:1.00lb (0.45 kg)
