Description
Item# 7601
Features:
- Senses charging on two battery banks.
- Pull off and snap on insulating cover.
- LED indicates ACR status.
- 1 4″ x .032″ male quick connect terminal for ground.
- 7 16″ (11 mm) stud length to accept multiple cable terminals.
- Waterproof – rated IP67 for temporary immersion.
Specifications:
- Nominal Voltage:
- 12V DC
- 24V DC
- Start Isolation:Yes
- Amperage Operating Current:
- 90mA (Combine)
- 15mA (Open)
- Terminal Stud Torque:60 in-lb (6.78 Nm)
- Continuous Rating: 65A
- Intermittent Rating: 115A (5 min)
- Cable Size to Meet Ratings:6 AWG
- Maximum Cable Size:1/0 AWG
- Stud Material:Tinned Brass
- Terminal Stud Size:1/4″ – 20 (M6)
-
Relay Contact Position:
- Combine 30 sec:13.6V DC
- Open 10 sec:12.35V DC
- Open 30 sec:12.75V DC
- Open High:16.0V
- Under Voltage Lockout: 9.5V
- Weight:0.80lb (0.36 kg)
