Description
Item# 2142
Features:
- Compact design enables high density circuit protection configurations.
- Push-to-reset operation.
- “Trip Free” design cannot be held “ON” during fault current condition.
- Ignition protected – Safe for installation aboard gasoline powered boats.
- Captive star lock washers meet requirements for anti-rotation.
Specifications:
- Amperage:50A
- Maximum Voltage:120V AC
- 32V DC
- Circuit Breaker Type:Thermal trip, manual push-button reset only
- Terminal Stud Torque:30 in-lb (3.39 Nm)
- Interrupt Capacity:3000A 120V AC
- 5000A 32V DC
- Minimum Operating Temperature:-54° C
- Maximum Operating Temperature:74° C
- Mounting Screw Thread:8-32
- Terminal Stud:10-32 Stainless Steel
- Weight:0.16lb (0.07 kg)
