Description
Item# 7183
Features:
- Drop in replacement for 185-Series Circuit Breakers.
- Visible reset lever shows open condition.
- Ignition Protected
- Meets SAE J1171 external ignition protection requirements.
- Weather Resistant
- “Trip Free” – cannot be held closed after trip.
Specifications:
- Amperage:50A
- Maximum Voltage:48V DC
- Mounting:Surface Mount
- Circuit Breaker Type: Thermally responsive Bi-metal blade
- Terminal Stud Torque:60 in-lb (6.78 Nm)
- Interrupt Capacity: 3000A 48V
- Minimum Operating Temperature:-40° C
- Maximum Operating Temperature: 85° C
- Circuit Breaker Class:Type III – switchable/manual reset – trip free
- Terminal Stud:M6 (accepts 1/4″ Ring Terminal)
- Weight:0.50lb (0.23 kg)
