Description
Item# 7080
Features:
- Visible reset lever shows open condition.
- Ignition protected – Safe for installation aboard gasoline powered boats.
- Meets SAE J1171 external ignition protection requirements.
- Weather Resistant
- Combines switching and circuit breaker function into one unit.
- “Trip Free” – cannot be held closed after trip.
Specifications:
- Amperage:25A
- Maximum Voltage:48V DC
- Mounting:Panel Mount
- Circuit Breaker Type: Thermally responsive Bi-metal blade
- Terminal Stud Torque:50 in-lb (5.65 Nm)
- Interrupt Capacity: 3000A 48V
- Minimum Operating Temperature:-40° C
- Maximum Operating Temperature: 85° C
- Circuit Breaker Class:Type III – switchable/manual reset – trip free
- Terminal Stud:M6 (accepts 1/4″ Ring Terminal)
- Weight:0.50lb (0.23 kg)
