Description
Item# 6006200
Specifications:
- Switch Type: Single Circuit ON-OFF
- Color:Black
- Switch Positions:2
- Battery Combine:No
- Alternator Field Disconnect: No
- Maximum Voltage:48V DC
- Stud Size:3/8″
- Terminal Stud Torque:120 in-lb (13.56 Nm)
- Continuous Rating: 300A
- Intermittent Rating: 500A (5 min)
- Cranking Rating 30 sec: 900A
- Battery Inputs:1
- Cable Clearance For 4/0 AWG Cables:1.12in (28.45 mm)
- Cable Size to Meet Ratings:4/0 AWG (120mm²)
- Mounting Holes:Accept 10 Screw
- Stud Material:Tinned Copper
- Stud Torque:120 in-lb (13.56 Nm)
- Terminal Stud Size:3/8″ – 16 (M10)
- Weight:0.65lb (0.29 kg)
